Leveling Base Adapter Plate
This kit consists of a Leveling Base Adapter Plate and four hex bolts, flat
washers, and lock washers. The Load Disc bolts onto the leveling base adapter
plate. This plate rests on four leveling nuts and washers screwed onto anchor
bolts installed in the foundation. By turning the leveling nuts, the height of the
load discs and thus the vessel, can be adjusted for proper load distribution.
Note:
Adapter plate not shown in
illustration at right.
This kit requires an adapter
plate for proper installation.
Chapter 1: Description of the Load Disc
1-4
