Inovonics FA575X User Manual

Fa575x, High-power repeater, Installation instructions

FA575X

High-Power Repeater

Exterior Installation Housing / without Transformer

Frequency Agile

900MHz

Installation Instructions

Rev. 1.00 08/24/2000

Specifications

Repeater housing dimensions:

6.38" x 3.60" x 1.10"

Repeater weight:

5.3 oz.

NEMA 4 enclosure dimensions:

7" x 7" x 3"

Enclosure + repeater weight:

20.7 oz.

Power requirement:

14VAC @ 20VA

(Optional) Backup battery:

12VDC

Low voltage threshold:

10.5-11.5VDC

MADE

IN USA

Product Description

The FA575 is a sophisticated repeater in a weatherproof enclosure that receives, decodes, and re-transmits signals from Ino-
vonics FA-series transmitters. It acts as a "range extender" for any decodable Inovonics transmission. The FA575 is intended
for quick and easy outdoor installation. (For applications that require neither the weatherproof enclosure nor the optional
backup battery, the repeater is available by itself as the FA570.)

M o u n tin g H o le s

(4 p la c e s )

E x a m p le : W irin g fro m re c e iv e r

to e x te rn a l d e vic e s

v ia k n o c k o u ts

W irin g K n o c ko u ts

(4 p la c e s)

R E P E AT E R

In sta lla tio n

1 ) T h e e n c lo su re c a n b e

m o u n te d w ith sc re w s
in se rte d in th e m o u n tin g
h o le s.

2 ) F le x th e re p e a te r c lip slig h tly

to in se rt th e re p e a te r.

3 ) F le x th e b a tte ry c lip slig h tly

w h e n in se rtin g a b a tte ry.

W irin g

1 ) W irin g sh o u ld b e ro u te d

th ro u g h th e o va l k n o c ko u t
in th e re p e a te r h o u sin g
b a se .

2 ) W irin g sh o u ld e x it th e

e n c lo su re th ro u g h
k n o c k o u ts in th e e n c lo su re
b a se .

AC PO W ER

B AC K UP P O W ER

D EC O D IN G

N O T A C TIV E

TRA N S M ITTIN G

Specifications

Receiver type:

frequency-hopping spread spectrum

Operating frequency:

902-928 MHz

Operating Environment:

32°-140°F (0-60°C),
up to 95% relative humidity
(non-condensing)
