Inovonics FA575 User Manual
Inovonics Sensors

© 1999 Inovonics Corporation.
All rights reserved.
02888
Specifications
Repeater housing dimensions:
6.38" x 3.60" x 1.10"
Repeater weight: 5.3 oz.
NEMA 4 enclosure dimensions: 7" x 7" x 3"
Enclosure + repeater weight: 20.7 oz.
Power requirement:
14VAC @ 20 VA
(Optional) Backup battery:
12VD
Low voltage threshold: 10.5-11.5VDC
Product Description
The FA575 is a sophisticated repeater in a weatherproof enclosure that receives, decodes, and re-transmits signals from Ino-
vonics FA-series transmitters. It acts as a "range extender" for any decodable Inovonics transmission. The FA575 is intended
for quick and easy outdoor installation. (For applications that require neither the weatherproof enclosure nor the optional
backup battery, the repeater is available by itself as the FA570.)
M o u n tin g H o le s
(4 p la c e s )
E x a m p le : W irin g fro m re c e iv e r
to e x te rn a l d e vic e s
v ia k n o c k o u ts
W irin g K n o c k o u ts
(4 p la c e s)
R E P E AT E R
In sta lla tio n
1 ) T h e e n c lo su re c a n b e
m o u n te d w ith sc re w s
in se rte d in th e m o u n tin g
h o le s.
2 ) F le x th e re p e a te r c lip slig h tly
to in se rt th e re p e a te r.
3 ) F le x th e b a tte ry c lip slig h tly
w h e n in se rtin g a b a tte ry.
W irin g
1 ) W irin g sh o u ld b e ro u te d
th ro u g h th e o va l k n o c ko u t
in th e re p e a te r h o u sin g
b a se .
2 ) W irin g sh o u ld e x it t h e
e n c lo su re th ro u g h
k n o c k o u ts in th e e n c lo su re
b a se .
AC PO WER
BACKUP POW E
R
DE CODIN G
NO T ACT IVE
TRA NSMITTIN
Specifications
Receiver type:
frequency-hopping spread spectrum
Operating frequency:
902-928 MHz
Operating Environment:
32°-140°F (0-60°C),
up to 95% relative humidity
(non-condensing)
