Inovonics FA536 User Manual
Fa536, Locator

FA536
Locator
Frequency Agile
®
900MHz
Interior Installation Housing
Installation Instructions
02803D
© 2001 Inovonics Wireless Corporation
02803D 05/19/2004
Specifications
Housing dimensions:
6.38" x 3.60" x 1.10"
Weight:
6.9 oz.
Power requirement:
14VAC (power adapter provided)
(Optional) Backup battery:
12VDC
Low voltage threshold:
10.5-11.5VDC
Maximum current:
75mA
Receiver type:
frequency-hopping spread spectrum
Operating frequency:
902-928 MHz
Operating Environment:
32° to 140°F (0° to 60°C),
up to 95% relative humidity
(non-condensing)
MADE
IN USA
Product Description
The FA536 is a sophisticated locator designed and intended for use by qualified OEM customers. The FA536 receives, decodes,
and re-transmits signals from Inovonics FA-series transmitters. The FA536 is used to determine the approximate location of
roving transmitters. The FA536 appends location identification data to signals initiated within its reception range. User-created
system software can then identify the general area from which the signal originated. The locator is not recommended for use in
multi-story buildings.
The FA536 is intended for quick and easy indoor installation. (Kits are available for outdoor installation.)
AC POWER
BACKUP POWER
DECODING
NOT ACTIVE
TRANSMITTING
