Hardy Floor Scales

FIG. 13 REMOVING THE SUMMING BOX LID

Installing the
Leveling Feet

Step 1.

Remove the lock bolt and nut from the lev-
eling foot.

Step 2.

With the scale raised and securely
blocked, insert the leveling foot into the
load sensor. Make sure the through hole in
the foot is aligned with the bottom through
hole on the load sensor. (See Fig. 14)
