Hardy Floor Scales - Manual (Page 11)

Hardy Floor Scales
2
WARNING FOR SCALES FITTED WITH AN INTE-
GRATED TECHNICIAN SUMMING CARD, DO
NOT EXCEED 5 VDC EXCITATION. DOING
SO MAY CAUSE PROPERTY DAMAGE. DO
NOT USE WITH ANY INSTRUMENT WITH AN
EXCITATION VOLTAGE ABOVE 5 VDC.
Load Points HARDY ADVANTAGE® Load Sensors
• Factory Matched
• Stainless Steel
• True Hermetic Seal
• No Cornering
Total Error 0.03% of FS Output
Maximum
Overload 100% of the Rated Scale Capacity
End Loading 100% of the Rated Scale Capacity
Temperature
Range • Operating -40º to +80º Degrees C (-40º to
+176º F)
• Ambient -10 to +40 Degrees C (+14º to 104º
Degrees F)
Temperature
Effect • On Output - 0.0011% of load/Deg. C
• On Zero - 0.0011% of FSO/Deg C
Cable Length 20 feet C2 Cable (6.096 meters)
NOTE: To purchase additional C2 Cable, contact our local
Hardy Process Solutions Representative or Hardy
Service Center.
Materials of
Construction
Steel • Carbon Steel: Type A36 carbon plate steel (slip
resistance - tread or smooth surface)
• Stainless Steel: Type 304 plate steel (slip resis-
tance - tread or smooth surface)
Paint Two-part UV resistant Polyurethane - 2 to 4 mil
top coat - Carbon Steel only.
Note: Stainless Steel scales are not painted)
