2 | Product description
8-cylinder open type compressor for external drive (V-belt or coupling)
with oil pump lubrication
2.1 Short description
Dimension and connection values can be found in Chapter 8.
Fig. 1
Fig. 2
Transport eyelet
Shaft seal
Shaft end
Leak oil drain hose
Discharge
shut-off valve
Suction
shut-off valve
Cylinder cover
Sight glass
Valve plate
Oil pump
Name plate
Base plate
