9| Dimensions and connections
SV
DV Suction line
Discharge line see technical data, chapter 8
A Connection suction side, not lockable
7/16“ UNF
A1 Connection suction side, lockable
7/16“ UNF
A2 Connection suction side, not lockable
7/16“ UNF
B Connection discharge side, not lockable
7/16“ UNF
B1 Connection discharge side, lockable
7/16“ UNF
B2 Connection discharge side, not lockable
1/8“ UNF
D1 Connection oil return from oil separator
1/4“ NPTF
E Connection oil pressure gauge
1/8“ NPTF
F Oil drain M26 x 1,5
H Oil charge plug M22 x 1,5
J1 Oil sump heater Ø 15 mm
K Sight glass 1 1/8“ - 18 UNEF
L Connection thermal protection thermostat
1/8“ NPTF
O Connection oil level regulator
1/2“ NPTF
X1 Connection for Schrader valve, suction side
7/16“ UNF
X2 Connection for Schrader valve, discharge side
7/16“ UNF
