Model II
Material
Name
Order-No.
fixed crushing plate
43.3010.09
movable crushing plate
43.3020.09
tempered steel
1 pair of support walls
43.3070.09
fixed crushing plate
43.3030.10
movable crushing plate
43.3040.10
stainless steel
1 pair of support walls
43.3080.10
fixed crushing plate
43.3050.08
movable crushing plate
43.3060.08
Hard metal tungsten carbide
1 pair of support walls
43.3090.08
fixed crushing plate
43.3100.27
zirconium oxide
movable crushing plate
43.3110.27
fixed crushing plate
43.3130.23
manganese steel
movable crushing plate
43.3140.23
Zirconium oxide plates must be used only for crushing ceramics and the like -
metals are not to be crushed.
Stainless steel plates and walls are recommended if moist/humid materials have to
be crushed which would lead to corrosion when using tool steel.
Hard metal tungsten carbide plates and walls are recommended in the case of very
hard materials to be crushed or if iron-contamination (from the abrasion of the
plates and walls) must be avoided.
5.2 Mounting the crushing plates (18, 22) and lateral support
walls (13)
When the jaw crusher is supplied, one set of crushing plates (18, 22) and lateral
support walls (13) is installed in the instrument. After the electrical connection, the
instrument is ready for operation.
The crushing plates (and to a very small extend also the support walls) are subject
to abrasion and must eventually be replaced.
(When checking the condition of the plates or if you realise while cleaning the
instrument that the plates are only abraded in their lower part, then these must not
yet be replaced but can simply be turned upside-down).
WARNING
Voltage!
Before starting the installation work, pull the mains
plug and secure against unauthorised reactivation!
Announce maintenance work with a warning sign.
