Page 10
3 Technical
Data
3.1 Dimensions
Model I + II: 72 x 41 x 83 (Höhe x Breite x Tiefe)
3.2 Weight
Model I: net 177 kg
gross 202 kg
Model II: net 205 kg
gross 230 kg
3.3 Working
noise
The noise level equals up to approx. 93dB (A).
3.4 Voltage, Current consumption, Power consumption
The machine can be operated at two levels of voltage:
Model I:
• single-phase alternating voltage 115V ± 10%, 21A, 1,9kW
• single-phase alternating voltage 230V ± 10%, 9A, 1,57kW
• 3-phase alternating voltage 200V ± 10%, 5,3A, 1,1kW
• 3-phase alternating voltage 400V ± 10%, 2,62A, 1,45kW
Model II:
• 3-phase alternating voltage 230V ± 10%, 9A, 2,78kW
• 3-phase alternating voltage 400V ± 10%, 4,95A, 2,2kW
• 3-phase alternating voltage 500V ± 10%, 5.15A, 3kW
• single-phase alternating voltage 230V ± 10%,13,5A, 2,36kW
Transient excess voltages are permissible in accordance with overload voltage
category II.
(See also chapter on 4.6 Electrical connection)
3.5 Electric
fuses
• The electric fuse is integrated in the protective motor switch, which is integrated
in the main switch (4).
3.6 Material
Feed particle size: Model I: approx. 60 mm
Model II: approx. 95 mm
Throughput: Model
I:
140kg/h
Model
II:
200kg/h
3.7 Final fineness
The final fineness depends on the inserted gap width and is between 1,0 mm and
15,0 mm.
