DOEPFER System A-100 BBD Module A-188-2
9
Controls:
1
a,
1
b : mix levels/polarities of the BBD taps
3328, 2790, 1726, 1194, 662 and 396
(polarizers)
2
a,
2
b Mix: wet/dry controls for outputs 1 and 2
(
1/2
a are assigned to sub-mixer 1)
( 1/2 b are assigned to sub-mixer 2)
3 Delay : manual delay/clock control
4 CV2: attenuator for CV2
5 Input Level: audio input attenuator
6 Feedback: feedback level and polarity control
(polarizer)
In- / Outputs:
!
CV1: CV1 input HSVCO
"
CV2: CV2 input HSVCO
§ Clk Out: clock output HSVCO
$ Clk In: BBD clock input
(normalled to Clock Out
§
)
% Audio In: audio input
&
Ext.FB In: external feedback input
(normalled to BBD Out
)
396)
/
Output 1: mixed audio output 1
(
Output 2: mixed audio output 2
) Single outputs: single audio outputs of the taps
3328, 2790, 1726, 1194, 662 and 396
=
CV Out: CV output HSVCO
Note: The labelling of the output sockets is wrong. The left
pair of sockets is Output 2, the right pair is Output 1
