4. In- / Outputs
! CV Y
This socket outputs the Y control voltage controlled
by vertical movement of the joy stick lever.
" CV X
This socket outputs the X control voltage controlled
by horizontal movement of the joy stick lever.
5. User examples
Module A-174 generates 2 manually adjusted control
voltages that can be used to control any parameter in
the A-100 system that is voltage controlled. Thus there
are manifold applications depending upon the modules
available in the existing A100 system.
Here is a list of some typical examples:
• Filter control
e.g. CV X : frequency, CV Y : resonance
• Mixing of audio or CV signals
e.g. CV X: CV for VCA 1 controlling level 1, CV Y:
CV for VCA 2 controlling level 2, both VCA outputs
are mixed together in an A-138
• Panning / Loudness
CV X : panorama position (CV for A-134),
CV Y : overall loudness (CV for 2 final VCAs)
