A-174, System a - 100, Overview a-174 – Doepfer A-174 Joy Stick User Manual
Page 2: Doepfer
A-174
Joy Stick
System A - 100
doepfer
2
Controls:
1
X Y :
Joy Stick (cross potentiometer)
2
Offs. :
Offset control for Y control voltage
3
LED’s :
Display of Y control voltage
4
Offs. :
Offset control for X control voltage
5
LED’s :
Display of X control voltage
In- / Outputs:
!
CV Y:
Control voltage output Y
"
CV X:
Control voltage output X
(X = controlled by horizontal movement
Y = controlled by vertical movement)
2. Overview
A-174
Joy Stick
➀
➁
➃
0
10
Joy Stick controlled CV
+
-
➂
CV
0
10
+
-
Y
X
CV
X
Y
Offs.
Offs.
➄
