doepfer System A - 100 Quantizer A-156
7
$ Trig. Out • ( Trig. Out
At the trigger outputs $ and ( a trigger pulse of
about 10ms duration is output whenever quantization
takes place, i.e. if the output voltage at the control
voltage output " or & changes. For example this
output can be used to trigger a envelope generator
(ADSR) with each new quantization step.
H
The pulsewidth is fixed to 10 ms. If during
this 10 ms a new trigger signal has to be
generated, re-triggering takes place. In this
case a 5ms pulse appears before the next
10ms pulse is generated.
) Transposing CV 1+2
The transpose input ) enables the simultaneous
transposition of both quantizer outputs. The voltage at
the transpose input ) is quantized to the nearest
semitone, and effects both quantizers, i.e. the vol-
tage at the transpose input is quantized and added to
both quantizer outputs.
Example: A voltage of +1.0 V applied to the transpose
input shifts both quantizer one octave up.
H
As the input and output range for all control
voltages is 0...+10 V the CV outputs " and &
stop at +10 V if the addition of input CV and
transpose CV would exceed +10V.
