A-146, System a - 100, Overview – Doepfer A-146 LFO 2 (variable Waveform) User Manual
Page 2: Lfo 2, Doepfer
A-146
LFO 2
System A - 100
doepfer
2
2. Overview
Controls and indicators:
1
Frequ. :
frequency control
2
Frequ. Range : switch for selecting frequency range
3
Waveform : control for adjusting the waveform or
pulse width
4
LED :
square wave frequency indicator
5
LED :
sawtooth / triangle wave frequency
indicator
In / Outputs:
!
:
output for normal square wave
"
:
output for positive square wave
§
:
output for sawtooth / triangle wave
Frequ.
Frequ.
Range
M
H
L
0
10
➊
➋
➌
➃
➄
➂
➁
➀
Wave
Form
Variable Waveform LFO
LFO 2
