A-133, System a - 100, Overview – Doepfer A-133 Dual Polarizer User Manual
Page 2
A-133
Dual VC Polarizer
System A - 100
doepfer
2
2. Overview
Controls and indicators:
1
LEDs :
negative/positive amplification display
(not a signal display !)
2
CV :
attenuator for the control voltage at
input ! that controls the amplification
3
Man. :
manual amplification control
In- / Outputs:
!
CV :
control voltage input
"
In :
signal input
§
Out :
signal output
➊
➋
➌
➁
➂
➀
