doepfer System A - 100 Modular Vocoder A-129 /3/4
3
A-129 /3
In- / Outputs:
! CV In 1 ... CV In 5 : CV inputs
" CV Out 1 ... CV Out 5 : CV outputs
§ Slew Control Input : Slew rate CV input; to
access the slew limiting ca-
pabilities, patch the A-129 /4
output & into it.
Controls:
1 Attenuator : Attenuator for the CV input
2 Offset : Offset control for the CV
output
A-129 /4
In- / Outputs:
$ Freeze Control Input : Gate input for controlling the
freeze function
% Slew CV : Slew rate control voltage
input
& Slew Control Outputs: 3 internally linked CV out- puts
to control slew rate
Controls and indicators:
3 Switch : Selector switch (3-position)
to choose "Freeze", "Slew",
or "Follow"
4 Manual Slew Rate : Knob for manual control of
the slew rate
5 Slew CV : Attenuator for output %
6 LED : Indicator showing slew rate
