doepfer System A - 100 VCO A-110
5
Sine Wave
Sine waves are pure waves: they just contain the
fundamental, without any harmonics (see Fig. 5). They
are thus not suitable for subtractive synthesis (shaping
sound with a filter).
Fig. 5: Spectrum of a sine wave
Frequency Modulation (FM)
Because the frequency of the VCO is controlled by the
voltages at inputs " and §, Frequency Modulation is
possible: frequency (pitch) is continuously varied by
the voltages at the CV input/s.
For instance, if the frequency of the VCO is controlled
by a slow LFO, you get typical vibrato (see Fig. 6).
Fig. 6: Frequency modulation using a slow LFO
(Vibrato)
If the modulation frequency is in the audio range,
completely different sounds emerge (see User Exam-
ples 6).
0%
100%
f
1
f
2
f
3
f
4
f
5
f
6
f
7
f
8
f f
9
Harmonics ➨
