The
grey marked cases are no longer available but have been added for the sake of
completeness.
In any case time lag (slow blow) fuses 5x20 mm have to be used ! Usually the type
of response is abbreviated by a character on the metallic ring of the fuse: F (fast), M
(medium) or T (time lag = slow blow). A fuse coded "T" has to be used ! Medium or
fast fast fuses are unsuitable and will blow. The reason for the time lag fuses is the
high transient current during power on that is ignored by the slow fuses. This transient
current is much higher for ring core/toroid transformer than for normal transformers. If
you still own an older A-100 frame or suitcase with the old version of the power
supply (A-100NT12, 650mA output current, manufactured until about 2001) a fuse
with 125 mA (230V) / 250 mA (115V) is required.
Case Version Mains Voltage
230V
Mains Voltage
115V
A-100G3 19" frame old version
(with 650 mA power supply A-
100NT12)
125 mA 250 mA
A-100G6 19" frame old version
(with 650 mA power supply A-
100NT12)
400 mA 800 mA
A-100G3 19" frame 3U/84HP 400 mA 800 mA
A-100G6 19" frame 6U/84HP 400 mA 800 mA
A-100P6 suitcase version 6U/84HP 400 mA 800 mA
A-100P9 suitcase version 9U/84HP 400 mA 800 mA
A-100LC6 low cost suitcase 6U/84HP 400 mA 800 mA
A-100LC9 low cost suitcase 9U/84HP 400 mA 800 mA
A-100LCB low cost base frame 2 x
3U/84HP
400 mA 800 mA
A-100PMS6 monster suitcase
6U/128HP
800 mA 1.6A
A-100PMS9 monster suitcase
9U/128HP
800 mA 1.6A
A-100PMS12 monster suitcase
12U/128HP
1,6 A 3.15 A
A-100PMB monster base frame
2x3U/128HP
800 mA 1.6 A
