Page 8 MTV16 Installation and User's Guide
Mounting
Before MTV16 is put into operation the board should be fixed on a suitable support and built into
a metal case (refer to EMC notes on page 4). The metal case should be connected to GND of
MTV16. We recommend to use the GND terminal of the power supply socket for this
connection. The MTV16 will work without housing too but in this case the assembly may exceed
the EMC radiation limits in your country.
The board measures about 78 x 67 x 25 mm. Four mounting holes with 3 mm diameter are
available for mounting the board on a bottom plate e.g. with distance sleeves or spacers (> 5
mm in length) and suitable screws. Pay attention that no short circuits are made – neither on the
top of the board (electronic parts) nor on the bottom (solder points or pcb tracks). In case of
doubt use isolating plastic parts (e.g. plastic screws, nuts and washers) for mounting.
Extent of delivery
The MTV16 delivery contains the following parts:
• MTV16 board, assembled and tested
• Two 10 pin ribbon cables with double row female connectors, about 30 cm each (for wiring
of the 16 analog voltages)
• This user's guide
•
Power Supply (230V mains voltage, European type mains plug, output voltage range
7...12V, current min. 100 mA)
included only for shipments within Germany, for shipments
outside Germany please contact your local representative or dealer
