pocketControl Owners Manual pocketControl Owners Manual Page 9
Description of presets
Preset 0: Volume [controller 7] (Channels 1-16)
Preset 1: Pan [controller 10] (Channels 1-16)
Preset 2: Filter Cutoff [controller 74] (Channels 1-16)
Preset 3: Filter resonance [controller 71] (Channels 1-16)
Presets 0 ~ 3 use a single controller type, with each knob relating to it’s corresponding MIDI channel, this allows full
control of 16 parts within a multitimbral sound generator, or realtime mixing in sequencer automation.
Preset 4: Volume / Pan [controller 7 / 10] (Channels 1-8)
Preset 5: Volume / Pan [controller 7 / 10] (Channels 9-16)
Preset 6: Filter Cutoff / Resonance [controller 74 / 71] (Channels 1-8)
Preset 7: Filter Cutoff / Resonance [controller 74/ / 71] (Channels 9-16)
Presets 4 ~ 7 use two controllers, one across the top row of knobs and the other across the bottom row. With Preset 4, the
top row is MIDI controller 7 (Volume) with the MIDI channel corresponding to the knob number, whilst the lower
row is MIDI controller 10 (Pan) on the same channel as the knob above it, hence knob 9 is channel 1, knob 10 is
channel 2 etc. Preset 5 follows the same idea except the MIDI channel is channels 9 to 16, so the actual MIDI channel
relates to the lower knob numbers. Preset 6, again follows the same idea as Preset 4 except the top row is MIDI
controller 74 (Filter Cut off ) and the lower row is controller 71 (Filter Resonance), and finally Preset 7 is the same as
Preset 6 except the channels are 9-16.
Preset 8: general controllers [controllers 0 - 15] (Master channel)
Preset 9: general controllers [controllers 16 - 31] (Master channel)
Preset 10: general controllers [controllers 32 - 47] (Master channel)
Preset 11: general controllers [controllers 48 - 63] (Master channel)
Preset 12: general controllers [controllers 64 - 79] (Master channel)
Preset 13: general controllers [controllers 80 - 95] (Master channel)
Preset 14: general controllers [controllers 96 - 111] (Master channel)
Preset 15: general controllers [controllers 112 - 127] (Master channel)
Presets 8 ~ 15 are general controller sets, which transmit on the Master Channel. Where the receiving MIDI device can
be programmed to any controller it can receive, these presets maybe the only presets needed, although preset 8 is
perhaps best avoided for general use as it includes controller 0 (could trigger MIDI program bank changes) and controller
1 which is the mod wheel, although of course there may be instances when MIDI controller 1 is required, such as adding
a modulation wheel function to a keyboard (such as a digital piano). Preset 12 also needs to be used with caution, as
controller 64 is defined as the sustain/damper pedal function, and most devices will always receive this controller as
Damper or Hold.
Preset 16: GS / XG general controls [NRPN / controllers] (Master channel)
Preset 16 has the top row of knobs transmitting relevant NRPN controller data for GS/XG instruments, and the lower
row is general controllers:-
Knob 1 Filter Cutoff [NRPN]
Knob 2 Filter Resonance [NRPN]
Knob 3 Vibrato Rate [NRPN]
Knob 4 Vibrato Depth [NRPN]
Knob 5 Vibrato Delay [NRPN]
Knob 6 EG- Attack [NRPN]
Knob 7 EG Decay [NRPN]
Knob 8 EG Release [NRPN]
Knob 9 Pitch Bend [PitchBend]
Knob 10 Modulation [Controller 1]
Knob 11 Portamento Time [Controller 5]
Knob 12 Reverb Send Level [Controller 91]
Knob 13 Chorus Send Level [Controller 93]
Knob 14 Delay/Var Send Level [Controller 94]
Knob 15 Pan [Controller 10]
Knob 16 Volume [Controller 7]
Page 16
Preset 58 Yamaha CS1X control [NRPN / Controller] (Master Channel)
Knob 1 Filter Cutoff [Controller 74]
Knob 2 Filter Resonance [Controller 71]
Knob 3 Vibrato Rate [NRPN]
Knob 4 Vibrato Depth [NRPN]
Knob 5 Vibrato Delay [NRPN]
Knob 6 Envelope Attack [Controller 73]
Knob 7 Amplitude Envelope Decay [NRPN]
Knob 8 Envelope Release [Controller 72]
Knob 9 Pitch Bend [Pitch Bend]
Knob 10 Knob 3 Parameter [Controller 17]
Knob 11 Knob 6 Parameter [Controller 18]
Knob 12 Reverb Send [Controller 91]
Knob 13 Chorus Send [Controller 93]
Knob 14 Delay/Variation Send [Controller 94]
Knob 15 Pan [Controller 10]
Knob 16 Volume [Controller 7]
Preset 59 Waldorf Pulse Control [Controller] (Master Channel)
Knob 1 Filter Cutoff [Controller 50]
Knob 2 Filter Resonance [Controller 56]
Knob 3 Filter Cutoff Keytrack [Controller 51]
Knob 4 Envelope 1 Sensitivity [Controller 52]
Knob 5 Envelope 1 Attack [Controller 14]
Knob 6 Envelope 1 Decay [Controller 15]
Knob 7 Envelope 1 Sustain [Controller 16]
Knob 8 Envelope 1 Release [Controller 17]
Knob 9 LFO 1 Speed [Controller 24]
Knob 10 LFO 2 Speed [Controller 26]
Knob 11 VCF Modulation Amount [Controller 25]
Knob 12 Portamento Time [Controller 5]
Knob 13 Envelope 2 Attack [Controller 18]
Knob 14 Envelope 2 Decay [Controller 19]
Knob 15 Envelope 2 Sustain [Controller 20]
Knob 16 Envelope 2 Release [Controller 21]
Preset 60 Ensoniq ASR-X [NRPN / Controller] (Master Channel)
Knob 1 Filter Cutoff [Controller 74]
Knob 2 Filter Resonance [Controller 71]
Knob 3 Vibrato Rate [Controller 75]
Knob 4 Vibrato Depth [NRPN]
Knob 5 Vibrato Delay [NRPN]
Knob 6 Filter Envelope Attack [NRPN]
Knob 7 Filter Envelope Decay [NRPN]
Knob 8 Filter Envelope Release [NRPN]
Knob 9 Pitch Bend [Pitch Bend]
Knob 10 Modulation [Controller 1]
Knob 11 Envelope Attack [Controller 73]
Knob 12 Envelope Decay [Controller 76]
Knob 13 Envelope Release [Controller 72]
Knob 14 Velocity Sensitivity [NRPN]
Knob 15 Portamento Time [Controller 5]
Knob 16 Volume [Controller 7]
