Things You Should Know
• Under certain conditions (cold weather, high humidity, etc.) condensation will form
on the inside surfaces of your tent. Condensation is caused by water vapor from your
breath, perspiration, or any wet clothing inside your tent. It is NOT LEAKAGE through
the tent fabric. It can be minimized by removing wet clothing from your tent and by
providing good ventilation through the tent.
• Never store tent, even for a short period of time, without drying it thoroughly and
brushing off caked dirt. Do not pack stakes or poles inside your tent. Use a separate
storage bag.
• STAKES SHOULD BE REMOVED BY PULLING ON THE STAKE ITSELF. NEVER
PULL ON THE TENT FABRIC OR TENT STAKE LOOP TO REMOVE STAKE.
• TENT POLES SHOULD NOT BE LEFT TELESCOPED TOGETHER DURING
STORAGE.
• Do not leave your tent set-up for weeks at a time, be aware that exposure to the
ultraviolet rays of the sun can seriously damage material and/or cause it to become
discolored.
WARNING: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS
TENT FABRIC. This tent meets the flammability requirements of CPAI-84.
The fabric may burn if left in continuous contact with any flame source.
The application of any foreign substance to the tent fabric may render
the flame-resistant properties ineffective.
3 Raise Ends of Tent
– Insert grey shorter shock-corded
poles through pole sleeves marked
with grey binding at both ends of tent above
windows.
– Insert second pin (located near center of tent) of
pin & ring system into pole end.
– Go to opposite end of pole and
gradually apply pressure to the pole forming an
arch until you are able to insert the pin into the
pole end.
– Attach frame clips. (illus. 5)
4 Attach Rainfly
– Assemble rainfly poles by interlocking shock-
corded pole.
– Insert rainfly pole into pole sleeves
located at the center edges of the
underside of rainfly. (illus. 7), (illus. 8)
– Drape rainfly over tent, pole side
down. The rainfly poles should cover
the door and rear window of tent.
– Insert rainfly poles into grommets
on tent body. (illus. 6)
– Secure rainfly with attachments
located on underside of rainfly.
– Connect the elastic loops with
“S” hooks (found at the rainfly corners) to
fabric loops near frame clips.
– Stake out all guylines. (illus. 8)
–
Assemble and insert (short) Vertical Hinged
Door Pole through vertical sleeve and into
bottom pole stop. Gently apply pressure to insert
top end into top pole stop and zip sleeve closed.
(illus. 9, 10)
– Assemble and insert (long) Hinged
Door Pole through curved door sleeve
and into top pole stop. Gently apply
pressure to insert bottom end into bottom pole
stop and zip sleeve closed. (illus. 9, 10)
– Attach light kit. (See instructions in light kit)
illus. 6 Assembled tent
without rainfly.
illus. 5
Frame clips
illus. 8
Completed tent with rainfly.
Grey poles
Grommets for
rainfly poles
illus. 7 Insert rainfly
pole through pole
sleeve on underside
of rainfly.
End guylines
Stake down doormat
illus. 9 Hinged Door
Pole Stop illus. 10 Hinged Door
Long Door
Pole inserts
into sleeve
and pole
stops, then
zips in.
Vertical Door
Pole inserts
into sleeve
and zips in
illus. 10
Light
illus. 11
Charger
THE COLEMAN CO., INC.
3600 N. Hydraulic • Wichita, Kansas 67219
1-800-835-3278 • www.coleman.com
MADE IN CHINA
PRINTED IN CHINA REV. 9/07
WARNING: Fluorescent tube(s) contain mercury (Hg)
and must be recycled or disposed of according to local,
state or federal laws. Call (800) 835-3278 or visit
www.coleman.com/recycle/ for recycling instructions
or safe disposal locations.
