6.OSD - Motion, Clear OSD - Camera Setting
Some products may not be available in your country, please contact our distributor for more details Some products may not be available in your country, please contact our distributor for more details
13 14
ENGLISH
MOTION Motion control
AUTO FLIP
PROPORTIONAL PAN:
PARK TIME:
: Auto. Image flip in tilt range from 90° to
180°
depends on the zoom factor,
the dome will adjust the pan and tilt speed
automatically for comfortable viewing.
defines the idle time prior to start a
custom defined action( park action).The range is
from 1 to 240 minutes. This function can be
deactivated by setting the minute to 0.
PARK ACTION:
POWER UP ACTION:
FAN ENABLED:
TEMP C/F:
the action which will be started after
the idle time (park time). Selectable between Preset,
Scan, Pattern (Nr), Tour or None.
defines the action which will
be started after power up and self test. Selectable
between Auto,Preset 1, Scan, Pattern (Nr), Tour or
None. By selecting Auto, the dome will resume the
last action before power off.
Activate Fan when the dome reach the
temperature.
Switch the temperature unit between Celius and
Fahrenheit.
Advance Setting
EIS ENABLED: E I S
PRESET FREEZEN:
AUTO FOCUS:
DEFOGGER:
HEAD UP:
Enable „ lectric mage tabilization“. This
function is variable on certain camera modul.
Freeze the image immediately.
Switch ON/OFF the Auto Focus
Activate Heater/Fan on the cold temperatur.
Switch ON/OFF the proportional PT moving. Can
combine with Camera Flip function.
AUTO FLIP ON
PROPORTION PAN ON
PARK TIME 005
PARK ACTION SCAN
POWER UP ACTION AUTO
FAN ENABLED 040
TEMP C/F CENT
ADVANCE SETTING
BACK
EXIT
Clear
You can clear setting’s memory or reset the camear to
factory default. The follwing functions are supported:
- Clear Zones
- Clear all presets
- Clear all patterns
- Clear all tours
- Clear all windows
- Factory defaults
Warning: The clear action can not be undone.
once a item is cleared it is impossible to
retrieve the deleted setting. Please make sure
that the requested clear action is desired.
CLEAR
CLEAR ALL ZONES
CLEAR ALL PRESETS
CLEAR ALL PATTERNS
CLEAR ALL TOURS
CLEAR ALL WINDOWS
FACTORY DEFAULTS
RESTART
BACK
EXIT
ADVANCE SETTING
EIS ENABLED N/A
PRESET FREEZEN OFF
AUTO FOCUS OFF
DEFOGGER 015C
HEAD UP
OFF
BACK
EXIT
CAMERA SETTING
In camera setting menu, you can setup camera module
related settings. please note that depends on module’s
capability, some function may not available. please contact
your local sales representative for detailed information.
defines the speed when performing zoom
function.
Activate or deactivate the digital zoom
function of the camera module.
Select the Back Light Compensation mode,
improves the image when an object has strong back light.
Activates the Slow Shutter function
of the camera, which provides a higher light sensibility
in low-environment.
Activates the Wide Dynamic Range function, which
improves the image contrast when an object has very
strong light on background. Only available with camera
modules with WDR.
ZOOM SPEED:
DIGITAL ZOOM:
BLC MODE:
SLOW SHUTTER:
WDR:
CAMERA SETTING
ZOOM SPEED HIGH
DIGITAL ZOOM ON
BLC MODE OFF
SLOW SHUTTER ON
LINE SYNC N/A
WDR MODE
N/A
ADVANCE SETTING 1
ADVANCE SETTING 2
BACK
EXIT
ADVANCE SETTING1
IR CUT FILTER:
MAX GAIN:
EXPOSURE COMP:
Mirror:
Flip:
Enables the removal of Infrared Cutter
Filter (IRC), also known as “DAY/NIGHT” mode. with the
removal of IRC, the camera turns into Black/White mode and
has higher sensibility to low-light or IR-Light in the night.
Selectable between On, Off, Auto or Time. Only available
on camera module with IRC function.
improve the image quality in the Night modus
This mode fixes the shutter speed
of a short exposure.Configure the shutter speed of a long
exposure by setting the ratio with regards to a short
exposure with the exposure ratio parameter. Blocked-up
shadow correction is not performed in this mode.
This function reverses the camera horizontally.
This function turns the camera upside down.
ADVANCE SETTING 1
IR CUTTER FILTER AUTO
IR CUT ON TIME N/A
IR CUT OFF TIME N/A
THRESHOLD 10dB
MAX GAIN 28dB
EXPOSURE COMP OFF
MIRROR OFF
FLIP
OFF
NEXT
O
NEW PASSWORD : ******
ENABLE PASSWORD OFF
BACK
EXIT
LD PASSWORD : ******
CONF PASSWORD : ******
PASSWORD SETUP
TIME 00:00:00
DATE 01/01/01
DAY MON
BACK
EXIT
CLOCK SETTING
Password setup
You can change password to access the OSD menu.
Default Password is 000000.
Clock setting
Some function like Auto-Tracking require the timer for
activation.
Time:
HH:MM:SS
DATE: YY/MM/DD
DAY: MON-SUN
