COP-USA CD260XIRICR-WDR - Manual (Page 2)

1. CAM NAME
ON/OFF
ON:
ABCDEFGHIJKLM
NOPQRSTUVWYZ
abcdefghijklm
nopqrstuvwyz
‐ 123456789
<‐ ‐> CLR POS END
2. LENS
MANUAL / DC IRIS
CAMERA NAME:
Insert the Title name by moving
the joystick up/down/left/right.
and pushing the buttom.use the
bottom arrows if needs to change
any letter or number on the camera
name.
Use CLR to erase
Use POS to change the name
location on the Screen.
END to exit the camera name
MANUAL (IRIS MANUAL MENU)
Manual adjustment for the Iris.
Brightness(0~100)
3. EXPOSURE
AGC OFF/LOW/MIDDLE/HIGH
SHUTTER OFF/A.FLK/(1/160)~(1/90000)/x2~X512/AUTO
SENSE‐UP OFF/AUTO X2~ AUTO X512
INITIAL SET RESET BACK TO ORIGINAL SETTING
PREVIOUS Back to Main Menu
Brightness(0 100)
REACTION SPEED(0~8)
DC IRIS(DC IRIS MENU)
Adjust DC IRIS brightness and iris response
speed.
BRIGHTNESS(0~100)
REACTION(0~8)
PREVIOUS
AGC:
Automatic Gain Control can be set to LOW, MEDIUM,
HIGH or OFF. In a dark environment, when AGC is set
to High, the image becomes brighter. The setting here
is related to the setting in Day & Night mode .
SHUTTER:
Electronic Shutter allows the shutter speed to be
adjusted from X256 to 1/90,000, including a choice for
A.flicker mode. In FLK mode, shutter automatically
asjusts to avoid image flicker when there is a
discrepancy between current and frequency. (If
MANUAL mode is selected in Lens, this will be AUTO.)
SENSE‐UP:
Sense Up can be set to X2 to X512 (X8 is default) or
turned OFF. When it is on, the camera controls
sensitivity as it automatically detects the light level in
dark environments and maintains a clear picture
INITIAL SET:
Reset to factory default settings.
