Chlp65ir-hsl, Professional camera

Professional Camera
CHLP65IR-HSL
· 1/3" SONY CCD High Resolution
· 560TVL (Enhanced 620 TVL)
· 0.001 Lux, Slowshutter (Sense up to 32X)
· Slelectable Speed Shutter 1/60 sec. to 1/12000sec.
· Super Digital Noise Reduction (SDNR)
· ALC Automatic Light Compensation
· 20X Optical Zoom 5~100mm
· Heater Blower Weatherproof Housing
· ASP IR Cut Filter Removable
· 114 High Intensity LEDs
· Non Polarity Power input
· Dual Power DC12V / AC24V 3.5A
Specification
Detail
Type:
Color Day / Night IR Cut Camera
Image sensor:
High Res. 1/3" Color CCD
Picture Elements:
NTSC: 811(H)x508(V) PAL: 795(H)x596(V)
Resolution:
560TVL
Mini Illumination:
0.001 Lux (Adjustable) 114 PCs High Power IR LEDs ON
Vertical Frequency:
NTSC: 59.94Hz PAL:50Hz
Horizontal Frequency:
NTSC: 15.734 KHz PAL:15.625 KHz
Clock Frequency:
NTSC:28 636Mhz PAL:28 375Mhz
Clock Frequency:
NTSC:28.636Mhz PAL:28.375Mhz
Scanning System:
2:1 Interlace
S/N Ratio:
More than 60dB
Electronic Shutter :
NTSC 1/60-1/12.000sec.; PAL1/50-1/12.000sec
Lens:
20X Optical Zoom 5-100mm ASP IR Lens (Auto Iris)
White Balance:
OSD
Backlight Compensation:
OSD
Auto Gain Control:
OSD
Gamma:
0.45
Video Output:
1.0Vp-p (75
Ω BNC)
Power Supply:
DC12V or AC24V (±10%)
Current Consumption:
DC12V/AC24V 3.5A
Recognition Distance:
15-30m
Dimensions:
20x23x60 cm
Weight:
4KG / 8Lbs
Storage Temperature:
-30°C ~ +60°C
Operating Temperature:
-10°C ~ +45°C
* Pictures and specifications are subject to change without prior notice
* Pictures and specifications are subject to change without prior notice
