ELECTROMATIC Equipment Co., Inc.
-4-
3.0 HOW TO CHOOSE TYPE OF PRODUCT
Since there is no unified manufacturing process of the measuring products the
adjustment of the switch can not be standardized. But there is always the
possibility of having your device calibrated by Checkline Europe. In this case we
need a pile of your product (2 cm thick) size A4 in a plastic wrapping that is as
tight as possible. You can classify your products by means of a comparison
measurement applying methods appropriate for verification according to
DIN20287. Take a 2 cm thick pile with an average quantity of moisture size A5,
weigh some of the sheets and dry them in a drying stove. Store the rest of the
paper in a plastic wrapping to preserve the moisture. The dried sheets of paper
are weighed again. By using the following formula the absolute moisture is
calculated.
Caution! The dried sheets of paper must not be used for measurement again.
M
n : mass of sheets with an average moisture.
M
t
: mass of dried sheets
%F: calculated absolute moisture.
100 % 


Mn
Mt Mn
F
Now take the rest of the pile out of the plastic wrapping and measure it with your
measuring device. Adjust the switch until the most exact value can be seen on
the display and note down the position of the switch.
ELECTROMATIC Equipment Co., Inc.
-13-
11.0 TECHNICAL DATA
dissolution
0.1% moisture of material
depth of measurement P2, P4:13mm
LM5: 5mm
measuring range P2: 3-10% moisture of paper
P4: 3-8% moisture of paper
LM5: 8-20% moisture of leather indication of %
refers to wet weight P2, P4: switch position 4,
LM5: switch position 2
working temperature 5°C to 35°C
temperature compensation P2:0,04%/°C,P4:0,03%/°C
LM5: 0,05%/C°
power supply 9V alkaline batteries or accumulator
drawing of current 5mA, sufficient for about 4000 measuring
procedures, when BAT appears on the display,
still about 200 measurements are possible
display three-digit LC-Display
size 60 x 120 x 26 mm
weight without battery about 140 gramms
delivery wooden case, proof plate, 9V alkaline
compound battery, case protection made of
rubber
