Checkline TMT-425 - Manual (Page 7)

 Electromatic Equipment Co., Inc.
-6-
6.0 MEASURING PROCEDURE
Important: For a correct measurement please ensure that the device has the same
temperature (+/-3°) as the material under test. For that reason, let your humimeter
adjust to the surrounding temperature of the material for at least half an hour before
measuring (protect from direct sunlight!).
1. Switch on the device by pressing the power
button ( ) for 3 sec..
2. If desired, the calibration curves can be
changed by using the arrow keys.
3. Insert the electrodes of the TMT-425 in the
material. The measuring values will be
displayed directly.
4. Save the displayed value in the store menu
(1x ) by pressing ( button). Saving the
value succeeded if the number in front of the
symbol increased.
5. To get into the store menu, press the left
button ( ) until the symbol appears.
6. Name the saved value by selecting .
 Electromatic Equipment Co., Inc.
-7-
7.0 PC CONNECTION AND DATA PRINT
The TMT-425 provides the possibility to transfer your
saved data to a computer. Use the supplied connection
cable to connect your gauge. Open the protective cover
of the TMT-425 carefully and insert the USB mini port B.
The bigger port has to be inserted in the USB output of
your PC.
Start the LogMemorizer Software and turn on the TMT-
425. The data transfer can be started either by the
software or by measuring gauge.
Data transfer by the humimeter TMT-425:
Press the
button until the main menu is opened (see
right picture). Select the menu item “Send logs” and
confirm with
. Then select “Manual logs” and confirm
again with . All stored values on your humimeter will
be transferred to your pc then.
Data transfer by your computer:
Open the LogMemorizer Software. Click on the button
“remote access” and a drop down menu will open. For
the data transfer, select the option “Import last manual
log” (last stored log will be transferred) or “Import all
manual logs” (all stored values will be transferred). Click
on one option and the data will be imported on the pc. It
is recommended to read the manual on the
LogMemorizer CD about further settings.
