12 1
CONTENTS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page
1.0 Overview & Operating Principle . . . . . . . . . . . . . . . 2
2.0 Operating Elements . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.0 Thickness Compensation . . . . . . . . . . . . . . . . . . . . . 4
4.0 Quick Start Instructions . . . . . . . . . . . . . . . . . . . . . 5
5.0 Calibration Notes . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5.1 Calibration with “Standard” Filaments
5.2 Special Calibration
5.3 NIST Calibration
5.4 Calibration Verification Schedule
6.0 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.1 High-Speed Guide Rollers
6.2 Lever Assembly
6.3 Air Dashpot Damping
7.0 Model Data & Specifications . . . . . . . . . . . . . . . . . . 12
7.0 DXN MODEL DATA & SPECIFICATIONS
Accuracy* ± 1% of full scale or
± 1 graduation mark
on scale
Diameter of Scale 54 mm
Maximum Speed
(standard) 2000 m/ min
(optional) 3500 m/ min (K)
(optional) 5000 m/ min (HS)
Outer roller distance, c:c
DXN-30 to DXN-1000 EX 38 mm
DXN-200 to DXN-10K
100 mm
DXN-2K 150 or 200 mm
DXN-30K to DXN-50K 250 mm
Roller material
(standard) Hard-coated aluminum
(optional) Hardened steel (ST)
Ceramic (CE)
Phenolic (PH)
Housing material Die-cast aluminum
Dimensions 260 x 72 x 44 mm
(10.2 x 2.8 x 1.7 in.)
Weight 700 g (1.5 lbs.), approx.
* Using factory standard materials and procedures. Special calibration using
customer sample is available.
Specifications subject to change without notice.
OI803N
