6

9. Press ZERO to zero calibrate. Wait approx. 17

seconds. The display will change to show PEK after
blinking SCN. Do not press any other switches or
move the sensing shaft during calibration.

10. Hang the calibration weight on the hook and

stabilize; the larger characters on the display will
change. The force gauge is now ready for full-scale
calibration.

11. Press the PEAK switch to begin full scale calibration.

Display blink SCN. Do not press any other keys or
touch the weight during calibration. After approx.
17 seconds the display blinks END, then after approx.
5 seconds the display blinks OK.

12. If calibration was successful, the display will show

OK momentarily (see above picture.). Press the UNIT
switch, then automatically power off.

13. If calibration was unsuccessful, the display will show

ERR. Remove the calibration weight, then press UNIT
switch. Repeat the procedure 6-9.

Err

88888

Calibration

1. A secure calibration stand to mount a force gauge

upside-dawn.

2. The appropriate calibration weight for your force

gauge. (Metric only!)

3. Turn POWER off.
4. Mount the force gauge upside down on the

calibration stand.

5. Attach the fixture on the sensing shaft of the force

gauge, carefully threading it finger tight.

6. Press and hold the UNIT, PEAK and ZERO switches.
7. Press and release the POWER switch (while continuing

to press UNIT, PEAK and ZERO) until the smaller
characters at the top of area of the display show
CAL. Release the UNIT, PEAK and ZERO switches. The
force gauge is now in calibration mode.

8. Press the UNIT switch. The display will show ZER after

blinking SCN for 10 seconds. The force gauge is now
ready for zero point calibration.

MODEL

MODEL

MODEL

MODEL

MODEL

CODE

CODE

CODE

CODE

CODE

WEIGHT

WEIGHT

WEIGHT

WEIGHT

WEIGHT

FGE/V-0.5X

02

200 g

FGE/V-1X

03

500g

FGE/V-2X

04

1Kg

FGE/V-5X

05

2Kg

FGE/v-10X

06

5Kg

FGE/V-20X

07

10Kg

FGE/v-50X

08

20Kg

FGE/V-100X

09

50Kg

“End”

88888

“oK”

88888

“SCN”
88888

“SCN”
88888

PEK

88888

“SCN”

-00-

ZER

88888

CAL
-00-
