Syncore ® Accessories
48 version E
5 Appendix
5.1 Technical data
Connection to inert gas module cpl.,
vacuum connection 24 V
Power take-up for the vacuum connection 120 W max
Ambient temperature 5°C-40°C
Maximal gas overpressure 10 mbar
Temperature range, vacuum connection Room temperature up to +70°C
5.2 Materials used
Description Materials Material code
Rack Aluminium, anodized AL
Vacuum connection Aluminium, with PFA coating AL
Glass in vacuum connection Borosilicate glass, hardened 3.3
Vacuum hose Ribbed PFA PFA
Condenser unit R-4 Borosilicate glass 3.3
Sealing discs Rack R-6, R-12 PTFE coating PTFE/Gummi
Glass with residual volume appendage
Glass R-4 and Glass R-6, R-12 Borosilicate glass 3.3
Support discs Rubber
Sealing discs, Rack R-24, R-48 and R-96 Polyethylene PE
Cooling plate Aluminum, anodized AL
Inert gas module base plate Aluminum, PFA coated AL
Inert gas module gas tube Silicone
Inert gas module septa Silicone, PTFE coated
Inert gas module screwed joints Polyethylether ketone PEEK
Inert gas cover sealing discs screw cap Polyethylether ketone PEEK
Reflux module/flushback module Aluminium AL
Reflux module/flushback module, cooling medium tube Silicone
Reflux module/flushback module, base
Polyethylether ketone PEEK
Table 4: Materials used
