6 Operation
14 Distillation Record 1.2 Operation Manual
6 .1 .1 Program buttons
Position Icon Info Function
Menu bar/
Tool bar
New Record File Opens a new File to start recording
Menu bar/
Tool bar
Open Record File Opens a saved Record File
Menu bar/
Tool bar
Save Record File
Saves the actual recording into a Record File with automatic
naming
Menu bar/
Tool bar
Save Record File as… Opens the ‘Save as…’ dialogue
Menu bar/
Tool bar
Close Record File Discard active recording (NO confirmation request!)
Tool bar Start Recording Starts recording
Tool bar Stop Recording Stops recording
Tool bar Auto Recording
Automatically starts recording when the START button is
pressed at the vacuum controller
Tool bar Show Report Shows the report from the last recorded data
Tool bar Reset Zoom Resets the zoom
6 .1 .2 Menu bar entries
File
Info Function
New Record File Opens a new File to start recording
Open Record File Opens a saved Record File
Save Record File Saves the actual recording into a Record File with automatic naming
Save Record File as… Opens the ‘Save as…’ dialogue
Close Record File Discard active recording
Exit Exit the program
