6 Operation
13 Distillation Record 1.2 Operation Manual
6 Operation
This section explains the different program views and handling steps.
6 .1 Program window layout
Distillation Record
Actual file Connection status


 
 f
Position Description
 Menu bar Click on text, to roll-out drop down menus
 Toolbar Program functions are available via buttons
 Program function window Access to program categories (will change the ‘Main view’ accordingly)
 Main view Displays main program information such as recording and configuration screens
 System status Shows the path where the actual file is saved
f Connection status Displays connection status of the vacuum controller
