Features and Specifications
• 1.54 Mbps DSSS Radio with High Speed SPI and UART Data Interfaces
• Serial data rate is 1.2 Mbps
• FCC/IC Certified modular approval
• 128 Bit AES Encryption – FIPS 197 NIST Certified
• 156 dB link budget with 19 dBi antenna
• 10 Watts EIRP with 19 dBi antennae (+21 dBm conducted)
• -97 dBm receiver sensitivity at 10
-4
bit error rate
• RF connector is RPSMA Female
• TDMA MAC supports up to 63 concurrent subscribers
• Power supply voltage 3.3 VDC
• Low power consumption: 0.75 Watts in transmit, 0.5 Watts in receive,
2 µW in sleep mode
• Wide Temperature range: -40
° to +80° C
• Narrow occupied bandwidth allows 29 channels at 2.4 GHz
• Small form factor allows easy integration: 47.5 x 51 x 7 mm, 10 grams
• Frequency Channels: 2.0833 MHz spacing and 1.75 MHz occupied bandwidth
Channel
Center Frequency
Channel
Center Frequency
0
Auto Mode
15
2.445833 GHz
1
2.416667 GHz
16
2.447917 GHz
2
2.418750 GHz
17
2.450000 GHz
3
2.420833 GHz
18
2.452083 GHz
4
2.422917 GHz
19
2.454167 GHz
5
2.425000 GHz
20
2.456250 GHz
6
2.427083 GHz
21
2.458333 GHz
7
2.429167 GHz
22
2.460417 GHz
8
2.431250 GHz
23
2.462500 GHz
9
2.433333 GHz
24
2.464583 GHz
10
2.435417 GHz
25
2.466667 GHz
11
2.437500 GHz
26
2.468750 GHz
12
2.439583 GHz
27
2.470833 GHz
13
2.441667 GHz
28
2.472917 GHz
14
2.443750 GHz
29
2.475000 GHz
