AIP-W411 150M Wireless 11N Router
- 86 -
Figure 4-81 Statistics
Current Statistics Status - Enable or Disable. The default value is disabled. To enable, click
the Enable button. If disabled, the function of DoS protection in Security settings will be
disabled.
Packets Statistics Interval （5-60） - The default value is 10. Select a value between 5 and
60 seconds in the pull-down list. The Packets Statistic interval indicates the time section of the
packets statistic.
Select the Auto-refresh checkbox to refresh automatically.
Click the Refresh button to refresh the page.
Sorted Rules - Choose how displayed statistics are sorted.
Click Reset All to reset the values of all the entries to zero.
Click Delete All to delete all entries in the table.
Statistics Table:
IP Address/
MAC Address
The IP Address and MAC address are displayed with related statistics
Total
Packets
The total
number
of packets received and transmitted by the Router.
Bytes
The total
number
of bytes received and transmitted by the Router.
Current
Packets
The total
number
of packets received and transmitted in the last
Packets Statistic interval seconds.
Bytes
The total
number
of bytes received and transmitted in the last
Packets Statistic interval seconds.
ICMP Tx
The number of ICMP packets transmitted to the WAN per second at the
