Technical Specifications
23
Miscellaneous
Operating system
Linux®
Front panel indicators
LED: Power-on, Genlock, Fan alarm, RAID alarm, System
alarm
Miscellaneous ports
Keyboard, mouse, SVGA display, Ethernet
GPI control inputs/outputs
25-pin D connector, future use
Serial control input
9-pin, EIA-422, future use
Cooling
Forced air
Power
100 to 240 volts universal, 50/60 Hz, 165 watts
Mechanical
3½” x 19” x 18” (89 x 483 x 457 mm) H-W-D
Mounting
Rack mount (2U), optional rear supports
Weight
27 lb. (10.6 Kg) net
Country of origin
U.S.A.
Agency approvals
UL, C-UL, CE, FCC Class A
1
The Broadcast Time Delay records and passes through all VBI lines between 11 and 22 (inclusive,
field 1 and field 2) in NTSC and lines 11 to 23 in PAL.
2
In PAL mode, special handling of line 11 Video Index data is enabled by default, but can be
disabled to allow normal reproduction of line 11. See Video Index below.
Video Index
Video Index is supported in PAL mode SDI input only. The data is used mainly to communicate
information about the format and aspect ratio of the video signal to down stream equipment. The
Time Delay does not take any action based on the Video Index data, it only passes it to the output.
When no valid Video Index data is present, no data is output.
In the event of total input signal loss (no SDI input carrier), whatever Video Index data was in the
last frame (including the case of no data) is held on the output.
The data passed as defined by SMPTE RP-186-2008 Class 1.1, is:
• Octet 1 - Scanning System, Active Format Description,
• Octet 2 - Signal Form Data Field and Reserved Data Field,
• Octet 3 - Sampling Structure Data Field and Reserved Data Field.
Video Index uses a special coding method that not only relies on the digital nature of SDI, but also
does not pass unaltered through MPEG encoding. The Time Delay takes the Video Index data from
line 11 and reinserts it on the output. This takes the place of normal video recording on line 11 in
both CVBS and SDI. To disable this feature for normal line 11 recording in CVBS or SDI:
1. Turn off the NumLock on the keyboard, hold the Shift and Control keys and briefly press the F12
function key.
2. A terminal window will open. Type “videoindex disable” and then Enter.
3. Power down the system and restart to effect the new configuration.
To restore Video Index operation, repeat the steps above using “videoindex enable”. The
current state of the unit can be determined by using simply “videoindex”.
