30
„ „ „ „
Charging the Battery Pack with the Battery Charger
Use the separately sold battery charger (included with the Battery/Charge Adapter
Kit BCA-CP100) to charge the battery pack NB-CP1L before attaching it to the
printer.
5
Connect the compact power
adapter cable to the printer.
• The indicator lights orange while charging
and turns off once the battery pack is fully
charged.
6
Disconnect the compact power
adapter cable from the printer
once charging is complete.
1
Remove the battery pack’s terminal cover.
• Refer to step 1 of the Charging the Battery Pack in the Printer section. p. 29
2
Attach the battery pack to the
charge adapter.
• Attach it firmly in the direction of the arrow.
3
Attach the AC cable to the compact power adapter CA-
CP100 and plug it into a power outlet.
• Refer to step 4 of the Charging the Battery Pack in the Printer section. p. 29
Indicator Compact Power
Adapter Cable
Charge Adapter
