1.44-MB Diskette Drive 1.44-MB Diskette Drive 1.44-MB Diskette Drive 1.44-MB Diskette Drive Size Size Size Size 3.5 in
LED Indicators LED Indicators LED Indicators LED Indicators (front panel) Green
Read/Write Capacity per Read/Write Capacity per Read/Write Capacity per Read/Write Capacity per
Diskette
Diskette Diskette Diskette (high/mid/low
density)
1.44 MB/1.2 MB/720 KB
Drive Supported Drive Supported Drive Supported Drive Supported One
Drive Height Drive Height Drive Height Drive Height 0.50 in (1.27 cm)
Drive Rotation Drive Rotation Drive Rotation Drive Rotation 300/360/300 rpm
Transfer Rate Transfer Rate Transfer Rate Transfer Rate (high/mid/low) 500/500/250 Kb/s
Bytes/Sector Bytes/Sector Bytes/Sector Bytes/Sector 512
Sectors/Track Sectors/Track Sectors/Track Sectors/Track (high/mid/low) 18/15/9
Tracks/Side Tracks/Side Tracks/Side Tracks/Side (high/low) 80/80
Access Times Access Times Access Times Access Times Track-to-Track (high/mid/low) 3/3/6 ms
Average (high/mid/low) 174/94/94 ms
Settling Time 15 ms
Latency Average 100 ms/83.3 ms/100 ms
Cylinders Cylinders Cylinders Cylinders (high/low) 80/80
Read/Write Heads Read/Write Heads Read/Write Heads Read/Write Heads Two
24X Max IDE CD-ROM 24X Max IDE CD-ROM 24X Max IDE CD-ROM 24X Max IDE CD-ROM
Drive (Slimline)
Drive (Slimline) Drive (Slimline) Drive (Slimline)
Disk Disk Disk Disk Applicable Disk CD-DA, CD-ROM (Mode 1 and 2)
CD-XA, CD-I (Mode 2, Form 1 and 2)
CD-I Ready, CD Extra, Video CD, CD-Bridge
Photo CD (Single and Multi-session)
CD-WO
Capacity 550 MB (Mode 1, 12 cm)
640 MB (Mode 2, 12 cm)
Diameter 4.7 x 3.15 in/12 x 8 cm
Rotational Speed 4200 rpm maximum
Center Hole 0.6 in/1.524 cm diameter
Thickness 0.047 in/0.12 cm
Track Pitch 1.6 µm
Block Size Block Size Block Size Block Size Mode 0 2,368, 2,352 bytes
Mode 1 2,352, 2,340, 2,336, 2,048 bytes
Mode 2 2,352, 2,340, 2,336, 2,048 bytes
Interface Interface Interface Interface IDE (ATAPI)
Access Times Access Times Access Times Access Times (typical) (typical) (typical) (typical) Random < 140 ms
Full-Stroke < 300 ms
Data Transfer Rate Data Transfer Rate Data Transfer Rate Data Transfer Rate Sustained 150 KB/s (sustained 1X)
Burst 2100 to 3600 KB/s
Cache Buffer Cache Buffer Cache Buffer Cache Buffer 128 KB
Start-up Time Start-up Time Start-up Time Start-up Time (typical) (typical) (typical) (typical) < 10 seconds
Stop Time Stop Time Stop Time Stop Time < 5 seconds
Operating Conditions Operating Conditions Operating Conditions Operating Conditions Temperature 41° to 120° F (5° to 55° C)
Humidity 10% to 80%
Dimensions Dimensions Dimensions Dimensions (HxWxD, maximum) 0.5 x 5.16 x 5.12 in (1.27 x 13.1 x 13 cm)
Weight < 0.75 lb (< 340 g)
Slim Line CD-RW/DVD- Slim Line CD-RW/DVD- Slim Line CD-RW/DVD- Slim Line CD-RW/DVD- Shipping Dimensions Shipping Dimensions Shipping Dimensions Shipping Dimensions 13.88 x 11.38 x 9.25 in (35.26 x 28.91 x 23.50 cm)
QuickSpecs
Compaq ProLiant DL380 G2 Compaq ProLiant DL380 G2 Compaq ProLiant DL380 G2 Compaq ProLiant DL380 G2
TechSpecs
DA - 10902 Worldwide — Version 50 — September 30, 2003 Page 37
