UPS Options

SNMP Serial Port Card

192189-B21

NOTE:

NOTE: Supports tower and rack UPS XR models ranging from 1000 – 3000VA.

Six Port Card

192185-B21

NOTE:

NOTE: Supports tower and rack UPS XR models ranging from 1000 – 3000VA.

High to Low Voltage Transformer (250VA)

388643-B21

NOTE:

NOTE: Supports R6000 UPS series only. 2.5 amps @ 125 Volts max output across two NEMA 5-15.

Extended Runtime Module, T1000 XR

218967-B21

NOTE:

NOTE: 2U each, two ERM maximum.

Extended Runtime Module, T1500 XR/T2200 XR

218969-B21

NOTE:

NOTE: 3U each, one ERM maximum.

Extended Runtime Module, R1500 XR

218971-B21

NOTE:

NOTE: 2U each, two ERM maximum.

Extended Runtime Module, R3000 XR

192188-B21

NOTE:

NOTE: 3U each, one ERM maximum.

Extended Runtime Module, R6000

347224-B21

NOTE:

NOTE: 3U each, two ERM maximum.

Extended Runtime Module, R12000 XR, 4U

217800-B21

NOTE:

NOTE: 4U each, two ERM maximum.

R12000 XR BackPlate Receptacle Kit, (2) L6-30R (NA)

325361-001

NOTE:

NOTE: The R12000 XR BackPlate Kit has a hardwired input.

R12000 XR BackPlate Receptacle Kit, (2) IEC-309R (WW)

325361-B21

NOTE:

NOTE: The R12000 XR BackPlate Kit has a hardwired input.

SNMP-EN Adapter

347225-B21

NOTE:

NOTE: Supports R6000 UPS series only.

Multi-Server UPS Card

123508-B21

NOTE:

NOTE: Supports R6000 UPS series only.

Scalable UPS Card

123509-B21

NOTE:

NOTE: Supports R6000 UPS series only.

Rack-Mountable PDU’s –

Rack-Mountable PDU’s –
1U/0U

1U/0U

(Up to 12 Outlets)

NOTE:

NOTE: 0U mounting brackets
shipped with
the unit (separate option kit for
1U mounting).

Compaq Power Distribution Unit-16A (200-240V) (WW)

207590-B21

NOTE:

NOTE: The 16A PDU also connects to the high volt models of the UPS R3000 XR (need cable PN
340653-001 (NA)) and the UPS R6000 models. Cable PN 340653-001 required if connecting to UPS
R3000 XR (192186-002 NA-High Volt model only).

Compaq Power Distribution Unit-32A (200-240V) (Int’l)

207590-B31

Compaq Power Distribution Unit-40A (200-240V) (WW)

207590-B23

NOTE:

NOTE: Please see the following Power Distribution Unit (Zero-U/1U PDU) QuickSpecs for
additional options including cables:

http://h18000.www1.hp.com/products/quickspecs/10838_na/10838_na.HTML

(North America)

http://h18000.www1.hp.com/products/quickspecs/10838_div/10838_div.HTML

(Worldwide)
