keys to scroll through all of the system’s input or output signals.
Press to return to the top level menu screen.
CANBus menus
There is one display screen for each CANopen module in the system.
The first line is a 16-character string (put in by the application engineer) that
identifies the product type and additional information.
The second line shows the CANopen Node ID and the bus status which is one of –
-OPERATING normal
operation
per
CiA
spec.
-STOPPED
stopped per CiA spec
-PRE-OP
pre-operational
(just powered up) per CiA spec
-RESET
just performed a power-on reset per CiA spec
-NO DATA
the module is not communicating
AI 10 11 12 V
9.99 9.99 9.99
Di11 12 13 14 15
1 1 1 0 0
OCI-1 BRAIN
ID 0 OPERATING
OCO-1 MAIN BANK
ID 102 OPERATING
OCO-1 AUX BANK
ID 103 OPERATING
OCI-1 BUCKET JS
ID 64 NO DATA
Do35 36 37 38 39
1 1 1 1 0
VDD POWER SUPPLY
12.34 Volts
PWM 11 PWM 12
45.5 % 100.0 %
