LOCATION OF CONTROLS (^0)
{""^-Please refer to the illustrations on pages 2 to 4.)
*Dolby NR function and live button are not pro
vided on the RQ-V190,
O
Fast buttons (FAST)
O Playback button (PLAY)
0 Stop button (STOP)
O Direction selector (DIR)
0 ^Dolby NR switch (□□ NR)
0 Headphones jack (Q)
0 XBS switch (XBS) *'
0 FM mode/tape selector
(FM MODEH-APE)
0 Volume control (VOLUME)
0 Tuning/time adjust buttons (-H, -)
0 Operation/battery check indicator
(OPR/BATT)
0 Hold switch (HOLD)
0 * Live button (LIVE)
0 Dual clock button (-DUAL CLOCK)
0 Band/mode select button
(•FM/AM/-MODE)
0
0
0
0
0
®
0
0
®
0
0
Memory select/memory scan button
(•M. SELECT/-M. SCAN)
Direct tuning buttons (*1, *2, *3)
Memory/time set button (MEMO T. SET)
Function selector (TAPE/fo^ RADIO)
Belt clip receptacle
Battery compartment cover
DC input jack (DC IN 3 V
)
Dual clock indicator (DUAL)
Stereo indicator (ST)
Live indicator (LIVE)
Hold indicator (SBZSi)
Memory mode indicator (
imodeu
imqde
^
)
Direct tuning indicator (DIRECT)
Multi indicator
Memory indicator (/¡Q)
Memory channel indicator
