FEATURE REFERENCE
(VOICE)
OCTAVE
The OCTAVE [▲] and [T] buttons can be used to shift
the pitch of the selected voice up or down by one or two
octaves. Press the [▲] button to shift the pitch up, or the
[T] button to shift the pitch down. The selected octave (-
2, -1,0,1, or 2) will be displayed on the MULTI DIS­
PLAY while the octave value is being adjusted, and for
approximately 2 seconds after either OCTAVE button is
released. A setting of 0 produces the normal pitch for the
voice. The normal octave (0) can be recalled at any time
by pressing both the CXTTAVE [▲] and [T] buttons at the
same time.
A
OCTAVE
SmE/SPLUVOtGE VOICE
n
u
STVLF SPLIT WOCF
In the SPLIT mode the left-hand voice octave can be shifted
after playing a left-hand key and the right-hand voice octave can
be shifted after playing a right-hand key.
The OCTAVE cannot be changed while the keyboard is being
played.
PAN
The PAN [A] and [T] buttons can be used to pan the
sound of the selected voice to any of 15 positions between
full left and right in the stereo sound field. Press the [A]
button to pan the voice to the right, or the [▼] button to
pan the voice to the left. The selected pan position will be
displayed on the MULTI DISPLAY while the pan value is
being adjusted, and for approximately 2 seconds after
either PAN button is released.
S^LE/SPlIt VOICE_____V
n
u
A
PAN
The PAN range is from -7 (full left) through 0 (center)
to 7 (full right). The center position (0) can be recalled at
any time by pressing both the PAN
[A] and [T] buttons
at the same time. The new PAN value will take effect as
soon as the next key is played.
• In the SPLIT mode the left-hand voice can be panned after
playing a left-hand key and the right-hand voice can be panned
after playing a right-hand key.
MIDI CHANNEL
The MIDI transmit channel for the selected voice is set
via the MIDI CH. [A] and [T] buttons in the VOICE
section. The [A] button increments the uansmit channel
number and the [▼] button decrements the channel
number. The current channel number is shown on the
MULTI DISPLAY while selection is in progress and for
approximately 2 seconds after both MIDI CH. buttons are
released. The MIDI transmit channel range is from 1 to
16.
A
MIDI CH
SiVLfc^ SPLIT VOICE VOICE
style shlit voice
Different transmit channels can be set for the left- and right-hand^
voices in the split mode — press a left-hand key prior to setting
the left-hand transmit channel, and a right-hand key prior to
setting the right-hand transmit channel.
The MIDI CHANNEL cannot be changed while the keyboard is
being played.
DUAL VOICE
The DUAL VOICE feature makes it possible to select
and play two different voices simultaneously.
To activate the DUAL VOICE feature press the [DUAL
VOICE ON/OFF] button (the indicator will light). When
ON, the voice selected prior to turning the DUAL VOICE
feature ON will sound simultaneously with a second
“dual” voice. Any voice can be selected as the dual voice
while the DUAL feature is ON, and its number will be
shown on the right two digits of the MULTI DISPLAY.
The DUAL VOICE feature can be turned OFF by presi^
ing the [DUAL VOICE ON/OFF] button a second time.
dual voice
^ON/OFF
u
STVLE/SPUTvaJCE VOCF
3 5
STYLt SPLIT voice SEAT
The AUTO HARMONY function (see page 25) applies only to
the main voice in the DUAL VOICE mode.
Only main voice data is transmitted via the MIDI OUT connector
on the specified MIDI channel for that voice (see above) in the
DUAL VOICE mode.
REVERB DEPTH (PSR-500), VOLUME, OCTAVE, and PAN can
be set independently for the main and sub voices in the DUAL
VOICE mode.
In the SPLIT mode the left-hand dual voice can be selected after
playing a left-hand key and the right-hand dual voice can be
selected after playing a right-hand key.
