CONNECTION

Connection to Camera

The ND/EXT connector is used to control the lens ND filter and extender It is not used if the lens does not have the ND

filter/extender Function

Bind and clamp unused connectors and cables, if any so they will not dangle while the pan/tilt head is in use

Select the necessary camera connecting cable from among the optional cables shown below

■ Camera pan/till head cable (for RS-232C, personal computer control)

AW-CA50A15 (for ccmposite video)
AW-CA50D15 (for component video)

■ Pan/tilt head cable (nc RS-232C control)
