Location of Controls
H
Power Supply Preparatior
Ф
О
Portable CD Player
Stereo earphones
® Hold lock switch (HOLD-LOCK)
( 2 ) Repeat button (REPEAT)
(g) Memory/recait button
(MEMORY/RECALL)
Skip/search buttons
(H^, «SKIP/-SEARCH)
(D Display
(§) Play/pause button (>■ 11)
® Stop/power off button
(■/POWER OFF)
(§) Remote sensor
(SENSOR)
® Extra anti-shock switch
(EXTRA ANTI-SHOCK)
@ Open button (OPEN)
Headphones volume control
(VOLUME)
® High filter/XBS selector
(HIGH FILTER, XBS, OFF)
® Headphones Jack (Q)
® Play mode selector (MODE)
® Push button (PUSH)
® Out jack (OUT)
® DC in jack (DC IN 4.5 V
)
® Hole for car mounting base
® Play/stop/off button
© Volume control (VOLUME)
® Hold switch (HOLD)
@ Plug
(D Skip/search buttons (—, +)
Refer to the specifications (page 11) for the durati<
dry cell batteries are used.
Using rechargeable batteries_________
Make sure that the rechargeable batteries have be
Recharging procedure
1 Place the rechargeable batteries
inside the unit.
(No batteries other than RP-BP60/
SH-CDB8D can be recharged.)
[f the battery compartment lid becomes dis­
engaged, position it horizontally and press it
back into position.
2 Connect the AC adaptor.
DC IN jack (DC IN 4.5V )
AC power outlet
Power
indicator
The power indicator is provided only for
United Kingdom.
The configuration of the AC adaptor differs
according to the area.
•When charging is commenced, the re­
charging indicator "B” flashes on the dis­
play panel.
• It takes about one and a half hours to
recharge the batteries fully at which point
the recharging indicator will go off.
3 Upon completion of the recharg­
ing, disconnect the AC adaptor
from the DC IN Jack and power
outlet.
Removing the batteries
Push the batteries upward in the direction of
the arrow to remove them.
•The batteries can be used for about
10 months (300 times) if they are used
every day.
They will need to be replaced if the duration
of their operation drops drastically.
