Specifications
CRT Size 17" CRT (16.0“ / 40.6 cm Viewable Image Size) Flat Square
Dot-pitch 0.27 mm (H: 0.236 mm x V: 0.137 mm)
Phosphor/Glass RGB short persistence (Hi-EU RED), Crystal Pigment / Dark tint
Surface treatment Advanced AGFiAS (Anti-Glare, anti-Reflective and Anti-Static) Coat
Input signals Video signaling RGB analog
Signal level 0.7 Vp-p (without sync, signal), 1.0 Vp-p (with sync, signal)
Sync, signal H / V separate (TTL level), H / V composite (TTL level),
Sync.-on-green is not available.
Frequency Range Allowable Horizontal Frequency : 30.0 kHz to 70.0 kHz
Allowable Vertical Frequency : 50.0 Hz to 160.0 Hz
Preset mode 1 preset and 7 reservation (See page 13)
Video Maximum Pixel Clock 108 MHz (typ.)
Resolution 1,280 dots (H)
X
1,024 lines (V) at 60 Hz*
Viewable Image Size Factory preset
(H X V, Diagonal) Full scan (Typical)
11.81" X 8.86", 14.8" Diagonal **
12.80"
X 9.60", 16.0" Diagonal **
Display Color Analog input, unlimited number of colors ***
Connectors Video Signal 15 pin mini D-Sub connector (female pins)
Power supply CEE-22 type 3-pin connector
Input power 100-240 V (50/60 Hz)
Power consumption 95 W typ. / < 15 W stand-by, < 8 W sleep mode (See page 12)
Controls Front Power ON / OFF, Q], a, B, H] keys
On screen display Contrast, Brightness, Size & Pos. ( H. Position, H. Size, V.
Position, V. Size), Geometry (V. Pincushion, Side Pin. Balance,
Trapezoid, Parallelogram), Rotation (Tilt), Color Temp. (9300 K
-H 8 MPCD, 7500 K, 6500 K, 5000 K, User Color adjustment),
Recall, Video Level select (0.7 V /1 V), Language select
(French, English, Spanish), OSD Position, Degauss, Signal,
Monitor Self-Test
Tilt/ swivel 13° up, 4° down, 90° each to right and left
Dimensions (W x H x D) 15.9" X 15.9" X 16.7"
(405 mm x 404.5 mm x 425 mm)
Weight (monitor only)
15.8 kg (34.7 lbs)
Approvals UL1950, CSA 22.2 No.950, DHHS,
FCC Class B, MPR II, NUTEK,
VESA DPMS /
E nergy S tar ®
Standard 1 detachable signal cable for VGA, SVGA
1 detachable AC power supply cord
Operating Instructions, Warranty card
Environmental conditions Operating
Temperature 0 to 35 'C (32 to 95 *F)
Humidity 5 to 90% (no condensation)
Altitude 10,000 ft
Storage
Temperature -20 to -t-60 °C (-4 to 140 °F)
Humidity 5 to 90% (no condensation)
Altitude 40.000 ft
Windows® 95 / 98 Plug & Play
VESA® DDC'TM 1 / 2B meets Windows® 95 / 98 Plug & Play
Requirements
Note;
• The on-screen image may flicker if the display is operated with the Vertical freq, under 60 Hz.
* This monitor may only be used in a commercial or industrial environment at resolutions above 1,024
x 768 at 75 Hz.
** Depends on signal timing used, see page 13,
*** Number of colors depends on the Video Board used, memory installed, and RAMDAC (Random Access Memory
Digital to Analog Converter).
Specifications and design are subject to change without notice.
This product may be subject to export controi regulations.
Weight and dimensions shown are approximate.
