GS series User’s Manual REV 2.1 22/01/12
9
Saved reading to memory Any reading can be saved anytime by
press MEM/ENTER key. A total of 500 readings can be stored in the
database include the reading unit.
Computer Control of Force Gauge A computer can control the force
gauge by sending USB commands.
USB Command Action
“m” Changing measure mode.
“u” Changing measure unit.
“z” Zero the gauge.
“r” Reset the gauge.
RS232 output signal The displayed reading may be transmitted to PC
by pressing the PRINT key or sending request command from PC to the
gauge
USB command Action
“l” Send live reading value with unit.
“p” Send peak tension value with unit.
“c” Send peak compression value with unit.
“x” or pressing
PRINT key
Send live reading value with unit, if current
mode is track mode.
Send peak tension value with unit, If current
mode is peak tension mode.
Send peak compression value with unit. If
current mode is peak compression mode.
“d” Send memory
“!” Send information of gauge (model, capacity,
serial number, firmware revision, original
offset, current offset, overload count).
