Operation 9145E Ethernet Network Interface Device User’s Manual
Interface Management
29
Table 4-2. User, Network, and Multipurpose Port LED Indications
4.2 Interface Management
The 9145E is managed locally through the console port and remotely either through the Manage-
ment UTP port or inband via the user port. The console port is connected to a VT-100 terminal,
through an emulation program, through the RS-232 serial port using a DE-9 cable. UTP is an out-
of-band 10/100 Mbps port supporting Telnet, SSH, and SNMP V1/V2C/V3 that is used for net-
work management.
4.2.1 Setting Up the VT-100 Terminal
When using the console port, you can use the HyperTerminal Emulation program that is included
with Microsoft Windows operating systems. The Telnet session is only available after the man-
agement TCP/IP configuration is completed.
NOTE: The Microsoft Vista operating system does not include HyperTermi-
nal. If your terminal interface computer uses Windows Vista, you
will need to use a separate terminal emulation program.
LED Name State Condition
SPD
Off
10BaseT
Auto
Connector Not Selected
Green 1000BaseT
Amber
100BaseT
System Test
Red Remote Fault (SFP Only)
Blinking Red Invalid/Unsupported SFP installed (SFP Only)
Slow Blinking Green* Connector Selected with No Link
LNK/ACT
Off
No link
No transmit or receive activity
Green Link on with full duplex
Blinking Green Transmission or receiving activity with full duplex
Amber
System test
Link up with half duplex
Blinking Amber Transmission or receiving activity with half duplex
Red
Port Disabled
LLF
Blinking Red No Link, but transmitting OAM packets in unidirectional mode
* Slow Blinking Green means the LED toggles between OFF and GREEN approximately once per
second.
