2 mdm / trm switch, 2 mdm / trm switch -3 – CANOGA PERKINS 2361 T1 Modem User Manual
Page 27
The EdgeAccess Universal Chassis System
2361 Modem Users Manual
3-3
3.1.2 MDM / TRM Switch
Found only on the standalone modem, the MDM/TRM switch indicates if the EIA-232 interface
is configured for connecting to another modem or a terminal (Selects DTE/DCE on the RS-232
interface).
Figure 20. LEDs, Interface, and Switches on the 2361 Standalone Modem
Alarm Connectors
Figure 21. ELIMs, OLIMs, and Alarm Connectors Are on the Rear
of the Standalone Modem
