EdgeAccess SNMP Managed Fast Ethernet Switch
Model 9135/9140 6-3
6.2 Switching Characteristics
Technology:
ASIC based parallel Store and Forward
Bridging:
Per IEEE 802.1d
Spanning Tree (with Management Board installed)
Address Table:
Maximum 8000 MAC addresses per switch in pool-mode
Forwarding Rate:
148,800 packets-per-second maximum per port
Filtering and Forwarding:
2 x 148,800 packets-per-second per Switch
Internal Bandwidth (Max.):
1 Gigabit per second
Buffer Memory:
1 Megabyte per port
Remote Fault:
For 100BASE-FX interfaces, when management is installed
6.2.1 Management Board – Characteristics
Hardware:
Optional field-installable module, hot-swappable with Reset button
(on front panel)
In-Band Support:
SNMP, TELNET, TFTP, BOOTP
MIBs Supported:
MIB II, Bridge MIB
Private MIB (contains RMON group 1 counters)
SLIP (Modem) Port:
EIA 232 protocol
DTE DE-9 female connector
Modem control
SLIP protocol
Terminal Port:
EIA 232 protocol
DE-9 male connector DCE
VT100 compatible
Software Download:
Via TFTP
Network IP Configuration:
Via BOOTP or User Entry
