CANOGA PERKINS 9140 Four-Port SNMP Managed Fast Ethernet Switch - Manual (Page 54)

5-8
To modify the Host Table or SNMP Settings, select the desired number 1-8. Press the key to scroll
through each of the possible selections (as prompted at the bottom of your screen after you have selected
the desired number), until the field you wish to configure or change is highlighted; press the key to
modify this field. Make any desired changes and press to complete the process. See Figure 5-10.
Figure 5 -10. Highlighted F ield to be C onfigured / C hanged.
5.2.1.3
SLIP Port Settings
To modify the SLIP Port settings, select the desired field (1-8) to change, press the key.
Figure
5 -11. SLIP Port Settings
Menu.
