EdgeAccess SNMP Managed Fast Ethernet Switch
Model 9135/9140 5-9
After you have selected the desired field to change, the current selection will become highlighted. Press the
key to scroll through available options.
The following options are available for each of the possible configurable options shown on figure 5-11:
• Interface: select either "direct" or "modem"
• Init Modem at Startup: select "yes" or "no"
• Modem Init String: the default Init String is ats0=1 (Advanced users only)
• Password enable: select "yes" or "no"
• SLIP Password: select a password of up to 15 characters
•
SLIP IP Address: enter the IP address of the Serial Line Interface Port. The SLIP address and the in-
band address must have different network IDs and cannot reside on the same network.
• SLIP Subnet Mask: enter the SLIP Subnet Mask
• SLIP Port Setup: select number 8, and a new menu will be displayed that details the
configuration of the SLIP Port. Enter the values shown in Figure 5-12.
Figure
5 -12. SLIP Port Setup.
5.2.1.4 Passwords
The 9135 Two-Port Switch and the 9140 Four-Port Switch has three levels of password protection:
• Supervisor highest level, can do anything
• Manager middle level, has some write access
• User mostly read-only access, can reset some counters
When entering a new password, you may select up to 18 characters. All letters, numbers and characters are
legal and your new password will be case sensitive. Reference Figure 5-13.
